DESCRIPTION
Professional Reticle Leveling System
by WHEELER ENGINEERING
Product Overview:
The Wheeler Engineering Professional Reticle Leveling System (PRLS) is a precision tool designed to allow a scope to be perfectly leveled on any firearm with ease. CNC machining, factory adjustment calibration set screws, anodized aluminum construction and a protective molded case put the PRLS in a class of its own. The system is comprised of two machined aluminum level housings calibrated to their integrated levels.
The Barrel Clamp Level is attached to the gun's barrel while the smaller Reference Level is placed on scope base, bottom half of a ring or other flat surface perpendicular to the vertical axis of the gun. The gun is then rotated until the Reference Level is aligned. The tuning adjustment knob on the Barrel Clamp Level is then turned until its level is centered to match the Reference Level. At this point, the Barrel Clamp Level is calibrated to the guns axis. The scope can be installed loosely and the Reference Level placed on top of the scopes turret cap. The scope is rotated until the Reference Level is aligned with the Barrel Clamp Level and then simply secured in place. The Wheeler PRLS is the most effective instrument available for precision scope alignment.
Includes:
- 2ea Machined Aluminum Level Housings
- Barrel Clamp Level has non-marring pads
- Fits around the largest diameter barrels, including shotguns
- Reference Level has magnetic bottom for stability
- Each level has an integrated bubble level for precise measurement
